Products

Search - Type

Category

Group

Series

thumbnail

PBS

Infra-red LED light source, distance measurement type obstacle detector. Fine settings available for each pattern, greatly improved than normal reflective photo sensors. Scanning angle: 180°, compact body with height of 60mm.

thumbnail

UAM-05LP-T301/T301C

A compact design for installation on AGVs, AGCs as well as in vertical guarding applications.

Conformity Standards
IEC61496-1/3: Type3
IEC61508: SIL2
ISO13849-1: PL d Category3

thumbnail

UBG-04LX-F01

28msec scanning time, suitable for high speed robots to avoid obstacles or make road map. 4m and 240° scanning range, DC12V.

thumbnail

UBG-05LN

Accuracy is greatly improved compared with PBS series. With DC24V, this sensor can be broadly used for control system or equipment. Field pattern: 31.

thumbnail

URG-04LN

The most compact obstacle detection sensor with distance measurement principle using laser. Able for delicate field settings. Scanning angle is 240°, broader than PBS series. DC5V.

thumbnail

URG-04LX

The first mass production model with the most compact size. Suitable for autonomous service robots as a means of environment and self-position recognition. With compact size and light weight, power consumption is very low. 4m and 240° scanning range, DC5V.

thumbnail

URG-04LX-UG01

Low price model. Best for beginners. USB bus power driven. Obstacle detection for autonomous service robots. Please use Classic-URG when higher accuracy is required.

thumbnail

UST-05LA

Upgraded with wider detection range and faster response time.More flexible field setting is available and even more suitable for obstacle detection of AGVs or load shifting detection.

thumbnail

UST-05LN

Upgraded with wider detection range and faster response time. More flexible field setting is available and even more suitable for obstacle detection of AGVs or load shifting detection.

thumbnail

UST-10/20LX

The smallest and lightest of its kind. The lightness at only 130g make it easy to install on even smaller robots or Unmanned Aerial Vehicles.

thumbnail

UTM-30LN

30m and 270° scanning range. Working under 100,000lx with IP64 protection structure. Suitable for security purpose as a monitor in outdoor environment. 25msec scanning time, also possible for sticking-out detection.

thumbnail

UTM-30LX

30m and 270° scanning range. Working under 100,000lx with IP64 protection structure. Possible for outdoor applications such as service robots. Suitable for robots with higher moving speed because of 25msec scanning time. DC12V.

thumbnail

UTM-30LX-EW

Ethernet interface type of Top-URG. Protection structure is improved to IP67 and it is more suitable for outdoor use even in the environment with 100,000lx.

thumbnail

UTM-30LX-FEW

Scaning speed 10ms! Ethernet interface type of Top-URG.

thumbnail

UXM-30LAH-EWA

Upgraded with finer resolution. Multi-echo functionality and IP67 protection for harsh environments such as rain, snow and fog.More flexible field setting is also available.

thumbnail

UXM-30LN-PW

Stable detection even targeting black objects. Multi-echo functionality and IP67 protection make it possible to operate under harsh environment such as rain, snow and fog.

thumbnail

UXM-30LX-EW

Stable detection even targeting black objects. Multi-echo functionality and IP67 available.

thumbnail

UXM-30LXH-EWA

Upgraded with finer resolution. Multi-echo functionality and IP67 protection for harsh environments such as rain, snow and fog.
